MTSi Si-Series

AMPLIFIERS


Overview      Configurations      Specifications



Performance: Power handling 20Hz-20kHz (with all channels clipping-12dB crest factor pink noise).
Recommended Loudspeaker Loads: Minimum 4Ω.
Frequency Response: 20hz-20kHz (+/- 0.5dB), any channel driven, less than 0.1%THD
Sensitivity: 1 Volt RMS.
Noise: Less than 100dB.
Input Clipping: +24dBu
Input Impedance: 10kΩ balanced
Output: Class D
Power Supply: Switch Mode Power Supply (SMPS) with Power Factor Correction (PFC). Auto ranging between 86-260 Volts (Appropriate fuses for power ranges 130V and 200-250V must be selected).
Connectors: Input/Output: Euroblock.
Cooling: Convection (The MTSi Class D/PFC technology does not require fans or external heatsinks).
Warranty Period: 3 Years. USA. For your country, see supplier’s information.
Dimensions: 2U Rack Height. 19”W x 17”D x 1.75” H (48.26W x 43D x 44.5H mm)
Shipping Weight: 14.5 kgs/32 lbs (8 channel version)
