MTSi AV-Series Specifications

AMPLIFIERS

Overview      Configurations      Specifications
Performance:Power handling (20Hz-20kHz with all channels clipping-12dB crest factor pink noise):

AV 754: 4 channel, 75W/4ohm, 40W/8ohm
AV 756: 6 channel, 75W/4ohm, 40W/8ohm
AV 758: 8 channel, 75W/4ohm, 40W/8ohm
AV 1502: 2 channel, 150W/4ohm, 75W/8ohm
AV 1504: 4 channel, 150W/4ohm, 75W/8ohm
AV 1506: 6 channel, 150W/4ohm, 75W/8ohm
AV 1508: 8 channel, 150W/4ohm, 75W/8ohm
AV 3002: 2 channel, 300W/4ohm, 150W/8ohm
AV 3004: 4 channel, 300W/4ohm, 150W/8ohm
AV 3006: 6 channel, 300W/4ohm, 150W/8ohm
AV 3008: 8 channel, 300W/4ohm, 150W/8ohm
AV 6002: 2 channel, 600W/4ohm, 300W/8ohm
AV 6004: 4 channel, 600W/4ohm, 300W/8ohm

Recomended Loudspeaker Loads:Minimum 4 ohms.
Frequency Response:20Hz-20kHz (+/-0.5dB), any channel driven, less than 0.3%THD
Sensitivity:1.22volts RMS (+4dBu) develops full output at minimum attenuation setting (Standard amplifier) and 0.308volts RMS (-8dBu) develops full output at minimum VCA attenuation setting (-S serial models only)
Noise:Less than 100dB
Input Clipping:
+24dBu
Input Impedance:
10kΩ balanced
Output:Class-D
Power Supply:Switch Mode Power Supply -SMPS with Power Factor Protector-PFC. Auto-ranging between 86-265 Volts, 43-63Hz. Appropriate fuses for power ranges 100-120volts and 220-240volts must be selected.
Connectors:Inputs & RS485 ports (-S models only): Euroblock 3 pin 3.5mm

Outputs: Euroblock 4pin 5.08mm, Network Neutrik EtherCon

Cooling:Air-Exchange: The MTS Class D technology does not require high volume forced fan cooling or external heatsinks. Instead, a small, low volume internal air-exchange fan is employed.
Dimensions:2U High (87.9mm), 19” wide (483mm), 18½” deep (470mm)
Shipping Weight:
14.5 kgs/32 lbs (8 channel version)
