Amplifier Specifications:
- 75 Watts, 4, 6, 8 channels, 70/100 Volt Line
- 150 Watts, 2, 4, 6, 8 channels, 70/100 Volt Line
- 300 Watts, 2, 4, 6, 8 channels, 70/100 Volt Line
- 600 Watts, 2 and 4 channels, 70/100 Volt Line
- Control & Monitoring of temperature, fault, HPF, Bridge, input signal, and gain, output voltage, current, power, impedance and gain.
- CobraNet® protocol for audio transport
- SNMP protocol for control and monitoring of amplifier variables.
- Optional DSP signal processor with BGM ducking on each input and compressor, and 8 band parametric equalizer on each zone output.
- Optional Enhanced DSP with ambient sensing
Basic 24/24 standalone System:
- 8 paging stations with DSP for compressor and parametric equalizer
- 4 channels for background music
- 1 channel of HDD based message system
- 1 channel of PABX
- 24 paging zones with built in DSP for ducking, compressors and 8 bands of parametric equalizer
- 4 Levels of Paging Priority
- CobraNet® audio transport over Ethernet (20bit, 48kHz sample rate, 5.33 milliseconds latency) fully compliant with IEEE802.xxx
- SNMP Control and Monitoring
Server based solutions in 16/512 or 256/512 configurations:
- 256 Paging stations/Background music channels with DSP for compressor or parametric equalizer
- Simple button or PC/Tablet based paging stations
- 32 channels of HDD based message system
- 8 channels of HDD or external BGM systems
- 8 channels of telephone/PABX paging systems
- 512 Paging Zones with inbuilt DSP for ducking, compressors and 8 bands of parametric equalizer.
- 20 levels of paging priority
- Event scheduling
- Event logging
- Paging Server redundancy
- Amplifier has sensing for: Fault, temperature, circuit voltage, current, impedance and power.
- Automated amplifier changeover in the event of a fault.
- Line monitoring for impedance, including open and short circuit
- LAN connection to security, building management systems, FIDS/PIDS
- CobraNet® audio transport over Ethernet (20bit, 48kHz sample rate, 5.33 milliseconds latency) fully compliant with IEEE802.xxx
- SNMP for control and monitoring
|
