| Performance: |
Power handling (20Hz-20kHz with all channels clipping-12dB crest factor pink noise):
COM 754: 4 channel, 75W @ 70 or 100 volt
COM 756: 6 channel, 75W @ 70 or 100 volt
COM 758: 8 channel, 75W @ 70 or 100 volt
COM 1502: 2 channel, 150W @ 70 or 100 volt
COM 1504: 4 channel, 150W @ 70 or 100 volt
COM 1506: 6 channel, 150W @ 70 or 100 volt
COM 1508: 8 channel, 150W @ 70 or 100 volt
COM 3002: 2 channel, 300W @ 70 or 100 volt
COM 3004: 4 channel, 300W @ 70 or 100 volt
COM 3006: 6 channel, 300W @ 70 or 100 volt
COM 3008: 8 channel, 300W @ 70 or 100 volt
COM 6002: 2 channel, 600W @ 70 or 100 volt
COM 6004: 4 channel, 600W @ 70 or 100 volt
|
| Frequency Response: |
20Hz-20kHz (+/-0.5dB), any channel driven, less than 0.3%THD |
| Sensitivity: |
1.22volts RMS (+4dBu) develops full output at minimum attenuation setting (Standard amplifier) and 0.308volts RMS (-8dBu) develops full output at minimum VCA attenuation setting (-S serial models only) |
| Noise: |
Less than 100dB |
| Input Clipping: |
+24dBu |
| Input Impedance: |
10kΩ balanced |
| Output: |
Class-D |
| Power Supply: |
Switch Mode Power Supply -SMPS with Power Factor Protector-PFC. Auto-ranging between 86-265 Volts, 43-63Hz. Appropriate fuses for power ranges 100-120volts and 220-240volts must be selected. |
| Connectors: |
Inputs & RS485 ports (-S models only): Euroblock 3 pin 3.5mm
Outputs: Euroblock 4pin 5.08mm, Network Neutrik EtherCon
|
| Cooling: |
Air-Exchange: The MTS Class D technology does not require high volume forced fan cooling or external heatsinks. Instead, a small, low volume internal air-exchange fan is employed. |
| Dimensions: |
2U High (87.9mm), 19” wide (483mm), 18½” deep (470mm) |
| Shipping Weight: |
14.5 kgs/32 lbs (8 channel version) |
|
|
